Model 2635S2-DW
The AQUA SOLUTIONS' Model 2635S2-DW is designed to dispense DI water to a glassware washer. The system provides DI water to the storage tank at a flow rate of up to 6-Liter/minute. The DI water in the storage tank is then available for use by the glassware washer at a flow rate of up to 40-LPM
This system is not designed for applications that require a continuous flow rate of 40-LPM. If the storage tank is emptied the system will provide DI water at a rate of up to 6-LPM.
The system includes a carbon pre-filter assembly, three 7" (178mm) diameter by 37" (940mm) tall DI tanks (two installed plus one spare), a 130-Liter pressurized storage tank with ¾” outlet valve, and a 2-Megohm-cm purity monitor with red and green LED’s.
When the red LED indicates that the system is no longer producing Type II DI water, the installed (and exhausted) DI tank in the first position is removed utilizing the tank's built-in quick-disconnect fittings. The second tank is then moved into the first position and the spare DI tank is easily installed into the rotation. The end-user can easily do this in a mater of minutes without assistance or tools.
The exhausted DI tank is then returned to AQUA SOLUTIONS for refilling. Since all of the system hardware is purchased, there are no monthly rental charges.
All AQUA SOLUTIONS' Type II Systems produce purified water that exceeds ASTM, CAP and CLSI specifications for Type II reagent grade water.
Features and Benefits
- The system includes one installed plus one spare DI module.
- Made in the USA.
- The sensor displays a Green LED when water quality is >2-megohm-cm and a Red LED flashes when it’s time to change DI Modules.
- Ion Exchange Capacity is 12,000 Grains.
- One (1) year warranty.
- You purchase and own the system hardware at a reasonable cost.
- The system is so easy to install, you can do it yourself.
- You can install the spare DI tank yourself, whenever you need it - even on weekends!
- If the DI tank exhausts in the middle of an experiment, or during a weekend, you can install the spare tank.
- See for yourself - compare the total cost of our Type II/III DI systems with the competition.
Pure Water Specifications
Resistivity 25°C: | >2-Megohm-cm at 25°C |
Conductivity | >0.500 MicroSeimens/cm at 25°C |
Pure Water Grade | Type II |
Flow Rate Details | 6-LPM from DI modules and 40-LPM from storage tank |
Storage Capacity | DI, 130-Liters |
Features and Benefits
Purification DI Modules | The system includes two installed plus one spare |
Country of Origin | Made in the USA |
Purity Sensor | The sensor displays a Green LED when water quality is >2-megohm-cm and a Red LED flashes when it’s time to change DI Modules. |
Ion Exchange Capacity | 12,000 Grains |
Warranty | 1 Year |
GSA | This item is on our GSA Contract # GS-07F-5799R |
No monthly rental charges | You purchase and own the system hardware at a reasonable cost. |
No installation charges | The system is so easy to install, you can do it yourself. |
No service charges | You can install the spare DI tank yourself, whenever you need it - even on weekends! |
Competitively priced | See for yourself - compare the total cost of our Type II/III DI systems with the competition. |
Optional Upgrades
2700N | Remote Dispenser kit - non-recirculating type - with 0.22 micron final filter capsule |
2700N-NFC | Remote Dispenser kit - non-recirculating type - no final filter capsule |
2701-DISP-6 | DI Spray gun 3/8" NPTF inlet and spray pattern outlet 1-GPM |
2635DI | 7" x 37", 6000 Grain, 1/2 ft³ Type 2 DI module for expansion or replacement |
CH1004-PF | 10" Pre-filter assembly with 5-Micron sediment filter |
DC2004 | 0.22-Micron (absolute) Final Filter Capsule |
DC2022 | High flow 0.22-Micron (absolute) Filter Capsule |
UV2006S | UV Sterilizer - Prevents the growth of microorganisms within the system. |
ROT-200TU-130 | Tank upgrade: Increases storage capacity from 130 to 200 Liters |
ROT-200 | 200-Liter presurized storage tank with valve assembly |
System Specifications
DI Modules | Includes two installed plus one spare 2635DI Type II Purifification Modules - 7" x 37", 6000 Grain, 1/2 ft³ |
Input Power | Requires a 110V outlet within 5 ft. of the purity sensor. |
Minimum Inlet Pressure | 25 PSI (1.7 bar) |
Maximum Inlet Pressure | 111 PSI (6.6 bar) |
Total Shipping Weight | 214 lbs (97 kg) |
DI Module Dimensions | Diameter 7" (178mm) Height 37" (940mm) |
Consumables
2635DIR | Type 2 Resin Refill for 2635DI Module (Exchange) |
CC1050 | 10" 1-Micron Activated Carbon Prefilter |
CN1050MP | 10" 5-Micron Sediment Pre-Filter - For use with optional CH1004-PF |
